Building a Kubernetes Debug Container Image with Docker

Building a Kubernetes Debug Container Image with Docker

Building optimized container images is a science 🧪 and an art 🎨. You need to know what you’re doing to get it right. In this post, we will build a Python-based 🐍 container image for troubleshooting Kubernetes ☸️️. Along the way, we will discuss some of the best practices for building images, when they apply and when they don’t! 🔍

For the impatient:
https://github.com/the-gigi/docker-images/tree/main/py-kube

“When you realize the difference between the container and the content, you will have knowledge.” ~ Idries Shah

Kubernetes is an unruly beast 🐉. I often need to get an inside look by running a debug container inside some pod or just a standalone debug pod. I also like to have nice things when I debug, so I created my own container image with some useful tools 🧰. Let’s break it down file by file!

This is not an introduction to Docker 🐳, containers, or images! If you’re new, let me GPT that for you:
https://letmegpt.com/search?q=docker

📁 The .dockerignore 📁

When you build container images, you might end up with a bunch of files that we don’t need in the final artifact. The .dockerignore file tells Docker to ignore certain files and directories when building the image. This is similar to .gitignore but for Docker.

# Git files
.git
.gitignore

# Documentation
README.md

# Build scripts
build.sh

# Temporary files
*.tmp
*.swp
*~

# Logs
*.log

When using multi-stage builds where you explicitly copy files from one stage to another, the .dockerignore file is not that important, because you can simply avoid copying unwanted files. So, the .dockerignore file is used as a blacklist, where multi-stage builds are more like a whitelist.

🧱 The Dockerfile 🧱

The Dockerfile is the blueprint for your image. It contains all the instructions for building the image. There is a LOT to talk about here. We will break it down into sections.

🧊 Picking a base image 🧊

First and foremost is the base image. You select it with the FROM statement.

# syntax=docker/dockerfile:1.3

FROM python:3.13-slim@sha256:21e39cf1815802d4c6f89a0d3a166cc67ce58f95b6d1639e68a394c99310d2e5

Picking a base image is a crucial step in building a container image. You want to pick a base image that is small, secure, and doesn’t contain a lot of stuff you don’t need. In this case, we are using the python:3.13-slim image, which is a minimal version of the official Python image. It contains only the essential packages needed to run Python applications. Note that I pinned the base image with a specific sha256 digest. This ensures that if I need to rebuild the image, the exact base image will be used. This is best practice for predictability and security 🛡️ since newer versions of the base image might have new vulnerabilities.

The reason I picked python:3.13-slim is that it is smaller than the full-fledged python:3-13 image, but it still contains a shell and everything needed to run Python scripts — which I want to do when I troubleshoot stuff 🐛. It is based on the Debian 12 image (Bookworm).

⚙️ Build arguments ⚙️

Next, we define two build arguments: KUBECTL_VERSION, which the caller can set at build time to specify the desired version of kubectl, and TARGETARCH, a built-in Docker variable that represents the target architecture. These are especially important for creating multi-platform images that behave consistently across different environments.

ARG KUBECTL_VERSION
ARG TARGETARCH

The reason we pass the kubectl version as a build argument is that we want to be able to build the image with different versions of kubectl. As we will see later, unlike other tools, kubectl is not available from the official APT repository.

🛠️ Installing OS-level dependencies 🛠️

The main job of the Dockerfile is to install dependencies on top of the base image. We use the RUN command to install them. Now, each RUN command creates a new layer in the image. This means that if you change a single line in the Dockerfile, all the layers after that line will be rebuilt. This can be time-consuming ⏳, so we want to minimize the number of layers we create. The smallest possible number of layers is one. Let’s do that!

The key is to chain all the commands we need with && \

Here we install all the OS-level dependencies using apt-get (the Debian package manager):

RUN apt-get update -y && \
    apt-get install -y --no-install-recommends \
      vim \
      curl \
      tree \
      dnsutils \
      apt-transport-https \
      ca-certificates \
      netcat-openbsd \
      redis \
      gpg \
      bsdextrautils && \
      ...

We use --no-install-recommends to avoid installing unnecessary packages. This is a good practice to control precisely what we install. We don’t specify the version of the packages, which is a bit risky. But in this case, we sacrifice some security for convenience. Managing explicit versions for every package is a lot of work. We will talk later about scanning the final image to give us some peace of mind 🔍.

The ... is there because we’re about to install more stuff into the same layer.

📦 Installing kubectl 📦

So, it turns out there is no Debian package for kubectl in the official APT repository ¯\(ツ)/¯. There are several good reasons for that which I won’t get into here. So, we need to do some extra legwork to install it. This block installs kubectl from the official Kubernetes APT repository:

  • Creates a secure directory for APT keyrings.
  • Downloads and de-armors the GPG signing key.
  • Adds the Kubernetes APT source URL for the given KUBECTL_VERSION.
  • Updates APT metadata and installs the kubectl package.

It’s a continuation of the same RUN command.

    ...
    # Install kubectl
    mkdir -p -m 755 /etc/apt/keyrings && \
    curl -fsSL "https://pkgs.k8s.io/core:/stable:/v${KUBECTL_VERSION}/deb/Release.key" | gpg --dearmor -o /etc/apt/keyrings/kubernetes-apt-keyring.gpg && \
    chmod 644 /etc/apt/keyrings/kubernetes-apt-keyring.gpg && \
    echo "deb [signed-by=/etc/apt/keyrings/kubernetes-apt-keyring.gpg] https://pkgs.k8s.io/core:/stable:/v${KUBECTL_VERSION}/deb/ /" | tee /etc/apt/sources.list.d/kubernetes.list && \
    chmod 644 /etc/apt/sources.list.d/kubernetes.list && \
    apt-get update -y && \
    apt-get install -y kubectl && \
    ...

🪣 Installing the MinIO client 🪣

We’re not done yet. Recently, I had to debug some MinIO-related issues, so I added the MinIO client to the image. This is a simple download of the binary and copying it to /usr/local/bin. But we need to make sure we download the correct version for the target architecture. This is where the TARGETARCH build argument comes in handy.

    ...
    # Install mc (MinIO Client) for the correct architecture
    MC_URL="https://dl.min.io/client/mc/release/linux-${TARGETARCH}/mc" && \
    curl -fsSL "$MC_URL" -o /usr/local/bin/mc && \
    chmod +x /usr/local/bin/mc && \
    ...

🐍 Installing Python packages 🐍

Next, we install some helpful Python packages. This is a simple pip install command. We use the --no-cache-dir option to ensure pip installs the packages without caching the downloaded files, keeping the final Docker image smaller and cleaner 🧼.

    ...
    pip install --no-cache-dir \
      kubernetes \
      httpie \
      ipython && \
    ...

The packages themselves are:

  • kubernetes - the Python Kubernetes client, in case I want to run some Python scripts that access the K8s API
  • httpie — a nicer cURL that I prefer
  • ipython — a better Python shell

🔐 Creating a non-root user and final cleanup 🔐

Next, we create a non-root user to run the container. This is a good security practice. If an attacker escapes the container due to some vulnerability, at least it won’t run as root on the node. If you do need to run as root for troubleshooting, just build a different debug image.

Finally, we clean up the APT cache and remove the package lists to reduce the image size and eliminate unnecessary temporary files. While it may not be significant for large images, it’s considered good practice and helps keep layers lean and reproducible 📦.

    ...
    # Create a non-root user
    useradd -m -s /bin/bash -u 1000 kuser && \
    apt-get clean && \
    rm -rf /var/lib/apt/lists/*

🧭 Setting workdir, user and command 🧭

The WORKDIR command sets the working directory for the container. This is where the container will start when it runs. It doesn’t matter much for a debug container, but it is a good practice to set it.

The USER command sets the user that will run the container — our non-root user.

Finally, the CMD command sets the default command to run when the container starts. In this case, we just want to start a bash shell 🐚.

WORKDIR /app
USER kuser
CMD ["bash"]

🏗️ The build.sh file 🏗️

OK. We have a Dockerfile. Now we need to build the image. The build.sh file is a simple script that builds the image using Docker’s buildx command, which provides extended build capabilities with BuildKit.

There are two parts to the build.sh file. The first part creates a new builder if it doesn’t exist yet. It also assigns the VERSION and KUBECTL_VERSION variables.

#!/bin/bash
set -e

VERSION=0.8
KUBECTL_VERSION=1.32

if ! docker buildx ls | grep -q "the-builder"; then
  docker buildx create --name the-builder --driver docker-container
fi
docker buildx use --builder the-builder

The second part actually builds the image. It uses docker buildx build to build for multiple platforms and sets labels, build arguments, and image tags. Then it pushes the image to Docker Hub 🚀.

docker buildx build \
  --platform linux/amd64,linux/arm64 \
  --build-arg KUBECTL_VERSION="$KUBECTL_VERSION" \
  -t g1g1/py-kube:${VERSION} \
  -t g1g1/py-kube:latest \
  --label "org.opencontainers.image.created=$(date -u +"%Y-%m-%dT%H:%M:%SZ")" \
  --label "org.opencontainers.image.revision=$(git rev-parse HEAD)" \
  --label "org.opencontainers.image.licenses=MIT" \
  --push .

echo "Image successfully built and pushed as g1g1/py-kube:${VERSION} and g1g1/py-kube:latest"

Building images in the CI/CD pipeline

Container images are best built in a CI/CD pipeline utilizing GitOps. This is a good practice because it ensures that the images are built using a well-defined process whenever the relevant files change and don’t depend on the discipline of specific engineers.

The py-kube image may not relly need a CI/CD pipeline, but why not? We’re already hosting the code on Github we may as well define a simple Github Actions workflow to build the image and push it to Docker Hub. The pipeline is defined in the .github/workflows/build-py-kube.yml file. It uses the docker/build-push-action action to build and push the image. As a bonus it also runs a Trivy scan on the image to check for vulnerabilities.

I will not go into too much detail here. Actually, I’ll go into no detail whatsoever, as Github Actions 🐙🐱 deserve their own blog post series. I’ll just dump the workflow file here. Enjoy!

name: Build and Push py-kube Image

on:
  push:
    paths:
      - 'py-kube/Dockerfile'
      - 'py-kube/.dockerignore'
    branches: [ main ]
  workflow_dispatch:

permissions:
  security-events: write

jobs:
  build:
    runs-on: ubuntu-latest
    steps:
      - name: Checkout code
        uses: actions/checkout@v4

      - name: Set up Docker Buildx
        uses: docker/setup-buildx-action@v3

      - name: Login to DockerHub
        uses: docker/login-action@v3
        with:
          username: g1g1
          password: ${{ secrets.DOCKERHUB_ACCESS_TOKEN }}

      - name: Get version from build.sh
        id: get_version
        run: |
          VERSION=$(grep ^VERSION= py-kube/build.sh | cut -d'=' -f2)
          echo "VERSION=$VERSION" >> "$GITHUB_OUTPUT"

      - name: Build and push
        uses: docker/build-push-action@v6
        with:
          context: ./py-kube
          file: ./py-kube/Dockerfile
          platforms: linux/amd64,linux/arm64
          push: true
          build-args: |
            BASE_IMAGE=python:3.13-slim@sha256:21e39cf1815802d4c6f89a0d3a166cc67ce58f95b6d1639e68a394c99310d2e5
            KUBECTL_VERSION=1.32
          tags: |
            g1g1/py-kube:${{ steps.get_version.outputs.VERSION }}
            g1g1/py-kube:latest
          labels: |
            org.opencontainers.image.created=${{ github.event.repository.updated_at }}
            org.opencontainers.image.revision=${{ github.sha }}
            org.opencontainers.image.licenses=MIT

      - name: Run Trivy vulnerability scanner
        uses: aquasecurity/trivy-action@7b7aa264d83dc58691451798b4d117d53d21edfe
        with:
          image-ref: docker.io/g1g1/py-kube:${{ steps.get_version.outputs.VERSION }}
          format: 'template'
          template: '@/contrib/sarif.tpl'
          output: 'trivy-results.sarif'
          severity: 'CRITICAL,HIGH'

      - name: Upload Trivy scan results
        uses: github/codeql-action/upload-sarif@v3
        with:
          sarif_file: 'trivy-results.sarif'
          ignore-unfixed: true

🐘 The Elephants in the Room 🐘

Let’s talk about some elephants. Why not use a Distroless image? Why not use Buildpacks? Why not use Kaniko? Why not use multistage builds?

The short answer is: this is a debug image, not a production microservice 🏭. It’s meant to be interactive, flexible, and it’s fine if it’s a little heavy. Distroless images are great for minimal, secure containers — but they don’t even include a shell. That’s a no-go for debugging.

Buildpacks are great for abstracting builds. But I want control over what goes into this image — including low-level tools like mc, kubectl, and netcat.

Kaniko is great for in-cluster builds. But I’m building locally or using Github Actions and pushing to Docker Hub, so BuildKit via buildx is just easier.

Multistage builds are awesome when you want to build the image in a rich environment with all kind of tools and generate a tight image based on a spartan base image like SCRATCH or Distroless with only the final artifact. But this is a debug image. The goal is to have all the tools available when I kubectl exec into a pod 🛠️.

🏡 Take home points 🏡

  • Understanding how to build efficient and secure images is essential
  • Debug images have very different requirements than production images
  • Always scan your images for vulnerabilities
